CGR Automotive

Yeah there's some nice stuff isn't there! We have a few other options too but they're the main track-focused ones we do which is what we specialise in.

So we thought we'd give a breakdown of the various suspension kits we offer for the GT86/BRZ Platform and show prices and specs of each kit to give you a good idea of what options you have in order to get the perfect set-up for you. It's a bit of a read so if you'd rather just speak to us direct, drop us a line and we'll happily go through the options with you The prices we're going to quote below will include our comprehensive fitting and set-up service which includes installation of your chosen kit, corner weight balancing to your specs and full 4 wheel-geometry and final set-up ready to get you straight on-track or to make sure your road car drives as well as it physically can. BC Racing; Bc Racing offer quite a range for the 86/BRZ platform, and value for money wise they're absolutely unbeatable, fully customisable to your specs too. BR - £1465 The BR Model is what we consider our entry-level kit, despite this the spec list is phenomenal and they're drive great on track and on the road. Camber adjustable front top mounts, combined 2-way adjustable damping and independent spring pre-load and height adjustment means you can truly get your set-up perfectly dialled in! The BR series coilovers use a large 46mm diameter piston in a 53mm diameter damper body to maximise oil capacity. As the damper unit opearates the oil contained within heats up. The viscosity of oil changes as its temperature varies which can lead to changes in the damping characteristics of the unit. RM - £1536 The BC Racing RM series feature high quality damping adjustable monotube inverted dampers at the front or front and rear, depending on vehicle. The RM coilovers offer the majority of the features of the BR series but with the additional benefit of the inverted damper unit. Inverting the damper unit brings with it a number of advantages. Unsprung weight is reduced by moving the oil and gas reservoir way from the hub and attaching it to the shell. Unsprung weight is vital to a cars performance as a lighter wheel and hub assembly which readily moves in response to road bumps will have more grip when tracking over an imperfect road. ER - £2050 BC Racings premium flagship coilovers are the external reservoir ER Series with separate compression and rebound damping adjustment. The ER Series coilovers bring with them the high quality and unique features seen on the BR and RM type but have the additional benefit of external reservoirs and the ability to allow the end user to individually adjust and set compression and rebound damping rates. The external reservoir ER Series coilovers allow BC Racing to increase the oil capacity of the damper unit. The additional oil capacity reduces peak oil temperatures which decreases variations in damping rates due to oil viscosity changes. The reduction in damping rate variations improves handling and ultimate on road and track performance. KW Suspension; KW are synonymous with suspension technology and winning races. They've been building suspension kits for decades so their development process and testing procedures are far beyond what most other competitors can offer, and this translates directly into their range of track products for the 86/BRZ platform. They also offer some more road-friendly kits, just get in touch for more information on those. Clubsport 2-way - £2978 The Clubsport kit has been specifically designed for cars wanting to run both on the road but also have excellent track performance, they come with a big advantage of having completely independent compression and rebound adjustment so you can truly get your set-up perfectly dialled in depending on which track you're at or where you're using the car. Some tracks will require completely different compression and rebound settings to others so you can really get your car setting the best laptimes by having these solely adjustable. They also come with camber adjustable top mounts, stainless steel construction for corrosion resistance, and pre-configured and thoroughly tested spring rates/valving - the ultimate Nurburgring tool. Clubsport 3-way - £4048 Using the same technology as the 2-way kit but with the added advantage of being able to adjust the low speed and high speed compression damping separately, as well as of course keeping the rebound damping completely independent. This is the perfect set-up for those wanting to keep the car balanced on tracks or bumpy b road where keeping the low speed and high speed compression adjustable is vital, mainly a more high-end track or racing kit the advantages can still be felt on the road. RSC Suspension; RSC Are a small swiss company who make extremely high quality suspension units built to order, fully customiable even down to the colour of the components units on the kits for that extra personal touch. RSC Competition Pro - £3361 The competition pro kit is designed for high-end fast road use or track-use and comes with some excellent features, camber adjustable top mounts, combined 2-way damping adjustment, 47mm piston diameter, Active Mechanic Progressive Adjustment (HPS AMPA™ System) (Automatic mechanically progressively regulating piston valves), Independent ride height and spring pre-load adjustment. The extremely responsive behaviour of the dampers means hitting big bumps and kerbs doesn't unsettle the car, and you can also run stiffer springs without reducing comfort as the dampers allow the wheel to move where it needs to without having to heavily damp the movement to stop resonance. Ohlins Road and Track - £2624 without top mounts/£3695 with top mounts front and rear Ohlins are possible the highest regarded name when it comes to suspension in the motorsport world, the build quality of all the components used in the Ohlins kits are second to none and the damping technology used is truly world class. They're DFV technology means excellent ride comfort while retaining body control on-track and through the corners ( https://www.ohlins.com/ohlins-unique-dual-flow-valve/ ). They're fully rebuildable and valving can be adjusted if necessary, with the top mounts selected you can then adjust the camber on the front and get solid rear damper mountings, 2-way combined compression and rebound adjustment, front strut is inverted for super low unsprung weight, independent height and pre-load adjustment with excellent corrosion resistance and finish. AST Suspension; AST Specialise in track set-up cars and kits specific to getting the most out of your vehicle on and off the track, by using high-end damping techniques you can retain road comfort while still setting healthy lap times, or go for a fully track specific set-up which will see you getting past cars you never thought you could, they also come with the option of double digressive pistons 5100 - £2690 Without Top Mounts/£3519 With Top Mounts The 5100 Series shock absorbers utilise inverted / upside down technology. The inverted design is race proven technology and produces an extremely strong damper, providing better suspension geometry under heavy lateral and braking loads as seen in a road and track environment. Rebound adjustable with independent height and spring pre-load, will come with adjustable drop link mounts too to save cost on adjustable drop links when setting the car up properly, inverted damper keeps unsprung weight to a minimum, optional double digressive pistons and optional DLC shaft coatings. 5200 - £4069 The 5200 Series are 2-way adjustable shock absorbers which are based upon competition 3-way adjustable shock absorbers. The 5200 shock absorbers are adjustable in compression and rebound. High end, track ready suspension that is totally streetable, fully upgradeable to 5300 spec, rebound and Compression Adjustable, remote reservoirs allow additional travel, heat dissipation and increased oil/ nitrogen gas capacity, 44.5mm diameter shaft struts are inverted and offer exceptional strength, which in turn reduces geometry change under corner and braking manoeuvres. 5300 - £4586 For the best performance on the track, AST Suspension designed the Competition 3-way adjustable series. The 5300 Series shock absorbers are rebound adjustable in 12 positions. The highspeed compression is adjustable in 12 positions and the lowspeed compression is adjustable in 14 positions. Both compression adjustments are made using an external canister. All adjusters work completely independent. Nitron Racing Shocks; Nitron boasts over a decade of success, celebrating prestigious race wins and lap records around the world. Designed, developed and manufactured in the UK. The manufacturing quality of Nitron products is absolutely unrivalled and this translates into a far better product both on and off the track. R1 - £3493 The NTR R1 system offers unrivalled performance and value with a design that gives drivers a wide range of effective, easy to use damping control. 2-Way combined damping adjustment. Developed from the R3 system, the R1 offers exceptional performance, reliability and value for both road and track use. With camber adjustable front top mounts, solid rear top mounts, independent height and spring pre-load and adjustable drop link mounts you can really get the R1 kit set-up for serious performance. The high-grade materials protect against corrosion whilst reducing weight. Every R1 kit is custom built, sprung and fully serviceable. Titanium and hard-anodised parts are hand built to last not only season after season, but also the harshest of winters. R3 - £4519 The NTR R3 system sets the standard for ultimate performance with a design that offers drivers and engineers unparalleled damping control. 3-Way independent damping adjustment. By incorporating our class leading large diameter piston and ultra-strong piston rod, the R3 system demonstrates outstanding levels of performance, damping control and adjustment. Piggyback or remotely mounted reservoir allows quick and simple independent adjustment of rebound and fast and slow compression damping. The large range of adjustment and quality of feedback allows the experienced driver to fully exploit the full potential of their car. The R3 is a proven race winner and lap record holder across a wide spectrum of international motorsport formulas. Intrax Suspension Technology; Intrax are without a doubt one of the best suspension companies worldwide, and produce some of the finest and best handling suspension kits physically available on the market today, they offer various guises, specs and options to suit every need allowing you to get the exact right set-up for your car. Before ordering we take many details including car usage, tyre size and type, wheel dimensions and type, and any other chassis changes e.g roll cage fitted, lightened e.t.c to make sure the damper set-up is built perfectly for your application RSA - £3220 Intrax chooses one knob for the damping adjustment. With this one knob you can set different damping settings. When you adjust the knob, both rebound and compression will be adjusted in the correct damping force. This unique system makes it very easy to find the correct setup for your driving style and road conditions. Finally the damping system is equipped with a heat device (thermostat) to insure damping force stability and optimum performance during all different operation temperatures. For the front we have a 40mm upside-down shock absorber. The RSA set can be equipped with an 1K2 46mm rear shock absorber, an aluminum lightweight, larger damper for better cooling. The 1K2 is very strong, suited for more circuit usage. - £3460 1K2 - £4060 We can also offer you a full 1K2 set for the front and rear with a larger diameter 45mm front struts for extra strength. The 45mm upside down configuration gives an even higher installation stiffness (less flex) in the Mac Pherson front suspension of your GT86/BRZ. Which enhances the handling, overall grip and feeling in the car. All the Intrax kits come with camber adjustable top mounts as standard, 4-way kits, XL upgrades and Intrax Proprietary Anti Roll Control options are also available as well as black titan coatings. For any more information on any of the kits above or for any of the products we sell, please don't hesitate to get in touch and see what we can do for you Info@cgrautomotive.co.uk www.Facebook.com/CGRAutomotive 01709 530871

We have some great black Friday discounts available on KW Suspension at the moment: We also sell, install and set-up a huge range of high quality suspension kits such as Ohlins, Nitron, RSC Intrax and BC Racing to name a few. We build our own extremely high-end exhausts in-house: https://www.cgrautomotive.co.uk/product-page/toyota-gt86-subaru-brz-exhaust-system-3-inch-70mm We do actually have a clearance exhaust that we need to sell to which if you're looking to buy over this weekend I may do for extremely cheap, especially if you buy some coilovers too! Feel free to call me on 01709 530871 if you need anymore info www.facebook.com/CGRAutomotive

We're gonna be in the workshop and office all day taking orders as our Black Friday deals are valid all weekend, make sure you don't miss out! Discounts of KW Suspension; https://www.facebook.com/cgrautomotive/posts/788813551303181 Discounts off Remaps in 2018; https://www.facebook.com/cgrautomotive/photos/a.349349538582920.1073741831.340718406112700/788887091295827/?type=3&theater 01709 530871 info@cgrautomotive.co.uk www.cgrautomotive.co.uk Or send us a Facebook message!

Just had an update from BC with some new models too; We can supply the HR and ZR kits for the GT86 and BRZ platform too. The ZR kit is the one to watch, as it had everything a super high-end damper would have, but at an affordable price. Inverted monotube dampers which are 3-way adjustable, with external reservoirs. High-speed and low-speed compression are adjustable independently as is rebound, camber adjustable top mounts where applicable as standard, huge damper bodies for extra stiffness and awesome damping capabilities. These are amazing pieces of kit to maintain comfort and bumpy road tracking but have ultimate performance on track, and completely adjustable for each condition. Flat, settled cornering no matter the condition, custom spring rates and valving available at no extra cost. RRP £1799

If you're after getting the handling nailed on your GT86, BRZ or any other model, we can now offer a huge range of suspension options. We offer fitting, corner weighting, geometry and alignment set-ups. If you choose to have your kit installed by us, we will offer a full "chassis workshop" where we will fit the kit, corner weight the car to your requirements (i.e driver weight and passenger if required), do a full 4 wheel alignment to specs that will suit your application, drive the car and adjust the damping until we feel it's set-up right and will require minimal adjustments by yourself. This is a crucial stage in getting your dampers set-up perfectly and makes all the difference when it comes to comfort and lap-times alike. Entry-level Fast-Road/Track Kit; BC Racing BR; RRP £849 These dampers are amazing value for money, they include adjustable damping, camber adjustable top mounts, custom spring rates/huge range available off the shelf, and the height of the car is adjusted by lowering the entire damper into the hub, meaning you don't lose damper travel no matter how low you run the car. The perfect kit for entry-level track driving or clubman racing, huge bang for buck and genuinely great pieces of kit. KW V1; RRP £966 KW are the house name when it comes to dampers and suspension, their V1 kit is designed as a plug-n-play kit to drop the height of your car, improve handling and comfort all in one hit. Very well made and german engineering. Pre-configured non adjustable damping designed to work in harmony with the factory car weight and driveability, attaches to the factory top mounts therefore retains factory geometry settings for camber. Clubman/Clubsport Mid-Range Kit; BC Racing RM; RRP £929 Almost the same spec as the BR's but with inverted monotube dampers, meaning there's less unsprung weight at each wheel as the damper is attached at the chassis end not the hub end, much more comfortable and better performance on track/on the road, especially over bumpier roads and circuits, the wheel can move with the road much easier as there's less weight to move, great upgrade over the BR. Fantastic choice for those looking to daily their cars as well as set great lap-times BC Racing ER; RRP £1499 Probably the best value for money suspension kit on the market, inverted monotube damper (where applicable), camber adjustable top mounts, independent compression and rebound adjustment, external oil reservoir which keeps oil at a consistent temperature and therefore the damper is subject to very little change in oil viscosity, far more sophisticated damping over the BR and RM kits giving great comfort but most of all amazing track performance. Mainly designed for cars driven to the track on race day, win their class then driven home again, great set-up for the Nurburgring or bumpy b-road. Can also be spec'd for fully fledged track cars with stiffer springs and damping if needed, can be used for competition. KW V3; RRP: £1588 The V3 kit from KW is a great choice for those looking for high quality, german engineered dampers, that come with independently adjustable compression and rebound damping, fantastic damping qualities and most importantly great track performance. These coilovers also provide excellent comfort on the road and will take a bumpy b-road with these while still keeping the car fairly flat and under control at all times. Clubman/Clubsport High-End Kit; KW Clubsport 2-way / 3-way RRP: £2520 / £3640 Designed and testing at the Nurburgring, the clubsport coilover kit is designed as the ultimate tool to drive your car to the ring and back again in comfort, yet set tyre scorching lap times with ease. Independent compression and rebound damping, camber adjustable top mounts, excellent damping capabilites and road handling. The 3-way option adds high speed and low speed compression as independent adjustment so you can truly get ultimate comfort by controlling roll and pitch (low speed compression) completely separately from harsh bumps, kerbs and sudden road surface changes (high speed compression) giving a truly advanced ride. Ohlins Road and Track Without / With Top-Mounts RRP: £1940 / £3020 The Ohlins brand speaks for itself, arguably the most highly regarding suspension manufacturer in the world. They feature Ohlins propriety Dual Flow Valve technology, which means under high speed compression the damper has essentially a built-in blow off valve, so the wheel and damper can move out of the way of the bump, kerb or pot hole then return back to the road surface quickly meaning no loss of traction and excellent comfort while retaining roll and pitch control perfectly. Available with or without camber adjustable top mounts, lowering is done via the hub mounting point so no loss of damper travel, aluminium components to keep unsprung weight to a minimum, and 1-way adjustable damping. In-Trax Racing Dampers RRP: POA We also have a great working relationship with In-Trax in the Netherlands who custom build suspension kits for us to spec and needs, there's no fixed price list for the Intrax kits as they're custom built and can be spec'd as needed. However the quality and ride is absolutely sublime. Coated struts for lower friction, inverted dampers, a multitude of damper adjustment options, camber adjustable top mounts, unlimited choice of spring rates. A truly custom set-up that is fully optimised for your application. Some of the best damping technology in the industry allows complete comfort without the cost of lap times, competitive racing spec body control as well as total comfort is possible without compromise. As each kit is custom built they are POA however we'll get some indicative prices from them so people can see what they'd expect to pay for a kit. For any more information or for even more options, please don't hesitate to get in touch. We can have custom set-ups built to your needs and cater for any uses, whether it's purely road, endurance racing or somewhere in between we can get a set-up that's perfect for you. info@cgrautomotive.co.uk 01709 530871 www.cgrautomotive.co.uk

The CGR Automotive Webshop is now live! 🛒🍾 We've only included a few products at the moment as all our website work is done in-house and we're by no means web developers so we're considering this a "beta" version. Keep an eye out for more products, info and content coming to it soon. In the meantime we'd appreciate it if you could take a look through the store and the website and let us know if there are any faults or improvements that could be made. Thanks and we look forward to hearing your feedback! www.cgrautomotive.co.uk/shop 01709 530871 info@cgrautomotive.co.uk www.cgrautomotive.co.uk

Is your car currently standard? We've had cars as low as 88db on a static test, drive-by is arguably more difficult to test due to there being so many variables but on a standard car there's no reason why we couldn't build something quiet enough. They're custom built to spec so if you say you want it quiet we'll build one to suit We actually have a couple of ex-demo/ put on the car, driven round for a bit to test the noise then taken off again in-stock if you wanted to look at that as an option, would save a little bit of cash too. Get in touch if you want to have a chat or need anymore details; 01709 530871 info@cgrautomotive.co.uk www.cgrautomotive.co.uk

Basically having the right length and diameter primaries are pointless with a badly designed collector as it'll negate any positive effects that should be caused by the tuned runners. If you look at our collectors the primaries always run parallel to each other before merging and normally they're very close together meaning the deflection between primary outlet and collector outlet is minimal meaning the velocity of gas leaving the collector is maximised and there's no resistance/back-pressure, plus the firing sequence is optimised in the collector which is something a lot of people/companies ignore for some reason.

Edit, price dropped to try get it shifted, it's Friday and it's got over £100 off just because it's taking up room we don't have at the minute, plus we'll include the postage so more like £150 saving! It's Friday and you deserve it

The 4-1 design we fitted to Rob's car was designed for more top end driving, the lengths and diameters are tuned to give a bigger increase in the higher RPM band as the car already has plenty of low-end torque and Rob agreed that this would be the best option. Just to clear a few things up; We can design a 4-1 system to give a bigger advantage at a low-mid rpm by tuning the lengths and diameters it's not strictly true that a 4-1 system only increases top-end. A 4-1 manifold will give much bigger increase at one RPM point compared to a 4-2-1 which would give a milder performance increase at two separate rpm points so essentially across a wider RPM band. You can tune 4-2-1 systems or stepped manifolds for high-end power too, but the increase is milder and across a slightly wider RPM band and generally not seen as advantageous on the road compared to a 4-1 manifold. By running equal length primaries, you will also get a lift across the entire torque band too, as well as the RPM point where the lengths and diameters are tuned for unlike and un-equal length manifold, and with more effect than a 4-2-1 manifold. The most important part really is the collector, this determines how much everything lifts by and how effective the primaries are, without a well designed collector, everything else is pointless (this is where most other manifold designers and manufacturers neglect). Hope this was helpful and any other queries don't hesitate to ask away

Thanks a lot Yeah unfortunately we have to move out by 8 o'clock on the Friday night as they move the rest of the show in. Was a fantastic show for us though, couldn't believe the reception we received!

No probs at all glad you're happy with it Cheers guys!

We're currently running a competition on our facebook page to win two Autosport tickets with live action arena tickets included, all you have to do is like and comment on the post below to be in with a chance of winning. If you could like the page and share the post too it would be much appreciated and you'll go down in our good books Cheers

Was just suggesting an alternative to replacing a failed part with one that will more than likely fail again I would give it a way for free, to the person who is kind enough to gift me £1078
